Application:：
Designed to provide insulation and mechanical protection in severe chemical and thermal environments. Used to cover hydraulic hose and couplings to prevent contamination and corrosion. The high mechanical strength and extremely low coefficient of friction make it good for reducing damage to bearing shafts and similar applications.

Specification AWG

Inside diameter(mm)

Outside diameter
(s)

Outside diameter (T)

Outside diameter (L)

Standard package (m/pc)

30

0.30±0.10

0.80±0.10

0.70±0.10

0.60±0.10

305

28

0.38±0.10

0.88±0.10

0.78±0.10

0.68±0.10

305

26

0.46±0.10

0.96±0.10

0.86±0.10

0.78±0.10

305

24

0.56±0.10

1.16±0.10

1.06±0.10

0.86±0.10

305

23

0.66±0.10

1.26±0.10

1.16±0.10

0.96±0.10

305

22

0.71±0.10

1.31±0.10

1.21±0.10

1.01±0.10

305

21

0.81±0.10

1.41±0.10

1.31±0.10

1.11±0.10

305

20

0.86±0.10

1.66±0.10

1.46±0.10

1.16±0.10

305

19

0.96±0.20

1.76±0.20

1.56±0.20

1.26±0.20

200

18

1.07±0.20

1.87±0.20

1.67±0.20

1.37±0.20

200

17

1.19±0.20

1.99±0.20

1.79±0.20

1.49±0.20

200

16

1.34±0.20

2.14±0.20

1.94±0.20

1.64±0.20

153

15

1.50±0.20

2.30±0.20

2.10±0.20

1.80±0.20

153

14

1.68±0.20

2.48±0.20

2.28±0.20

2.08±0.20

100

13

1.93±0.20

2.73±0.20

2.53±0.20

2.33±0.20

100

12

2.16±0.25

2.96±0.25

2.76±0.25

2.56±0.25

100

11

2.41±0.25

3.21±0.25

3.01±0.25

2.81±0.25

150

10

2.86±0.25

3.49±0.25

3.29±0.25

3.09±0.25

150
