| HWG Anti-tracking outdoor insulation tubing |
|
|
 |
26/35KV Cold-shrinkable terminal and splices for power cable:
Application:
Mainly used for the connection of cable terminal
|
●Excellent insulation and anti-tracking performance.
●Very good UV resistance.
●Standard color: red
●Regular size:1m, 1.2m |
Minimum shrink temperature: 90°C
Full shrink temperature: 110°C
Specification (mm) |
|
No. |
Items |
Unit |
Specification |
|
1 |
Shrink temperature |
℃ |
120±10 |
|
2 |
Tensile strength |
MPa |
³12.0 |
|
3 |
Elongation at break |
％ |
³450 |
|
4 |
Density (20℃) |
Kg/m3 |
1.10´103 |
|
5 |
Hardness |
Shore A |
<80 |
|
6 |
Water absorption |
％ |
< 0.5 |
|
7 |
Heat shock resistance |
200±2℃/4h |
No drop and
no flow |
|
8 |
Low temperature
flexibility |
-55±2℃/4h |
No crack |
|
9 |
Volume resistant |
W.cm |
³1.0´1014 |
|
10 |
Breakdown strength |
KV/mm |
³23 |
|
11 |
Performance after
heat aging |
Mpa
％ |
³9.0
³300 |
|
12 |
Anti-tracking |
KV/Class |
> 4.5 |
|
13 |
Eccentricity |
% |
£30 |
|
Specification |
Inside diameter
before shrink |
Inside diameter
after shrink |
Wall thickness
after shrink |
|
30/12 |
30 |
12 |
2.2±0.20 |
|
35/15 |
35 |
15 |
2.2±0.20 |
|
40/18 |
40 |
18 |
2.2±0.20 |
|
50/20 |
50 |
20 |
2.2±0.20 |
|
50/25 |
50 |
25 |
3.2±0.20 |
|
60/25 |
60 |
25 |
3.2±0.20 |
|
70/30 |
70 |
25 |
3.3±0.20 |
Dimensions are shown for reference purpose only. Specification subject to change. Products can be produced according to given specification. Please contact us for further information and confirmation.
| |
|
|
